Philips 49" Dual QHD 32:9 Curved USB-C Docking Monitor with 5MP Webcam
PRODUCT DESCRIPTION
Philips 49B2U5900CH 49" Dual QHD 32:9 Curved USB-C Docking Monitor with 5MP Webcam - 3 Years On-site Warranty
VA display
VA display delivers awesome images with wide viewing angles.
DisplayHDR 400
DisplayHDR 400 for more lifelike and outstanding visuals.
USB-C Docking with RJ45
RJ-45 to USB-C provides an easy, secure network connection.
SoftBlue Technology with Low Blue Light Panel
SoftBlue Technology: for comfortable viewing.
Need monitors for a whole office, classroom or gaming room? Email sales@sourceit.com.sg for volume pricing and delivery lead time.
Philips 49B2U5900CH Datasheet — Technical Specifications
General
| Product Name | Philips 49" Dual QHD 32:9 Curved USB-C Docking Monitor with 5MP Webcam |
| Model | 49B2U5900CH (Philips CTN 49B2U5900CH/69) |
| Brand / Series | Philips monitors |
| Local Warranty (Singapore) | 3 years on-site warranty |
| Pixel Defect Policy | Replacement if more than 2 dead/bright pixels in year 1, or more than 3 from year 2 onwards |
Picture/Display
| Panel Size | 48.8 inch / 124 cm |
| Aspect ratio | 32:9 |
| LCD panel type | VA LCD |
| Backlight type | W-LED system |
| Pixel pitch | 0.2328 x 0.2328 mm |
| Brightness | 450 nits (SDR), 500 nits (HDR) |
| Display colors | 1.07 B (8 bit + FRC) |
| Color gamut (typical) | NTSC 97%*, sRGB 119%* |
| Contrast ratio (typical) | 3000:1 |
| SmartContrast | 80,000,000:1 |
| Response time (typical) | 4 ms (Grey to Grey)* |
| Viewing angle | 178º (H) / 178º (V), @ C/R > 10 |
| Picture enhancement | SmartImage |
| Maximum resolution | 5120 x 1440 @ 75 Hz |
| Effective viewing area | 1191.936 (H) x 335.232 (V) - at a 1800R curvature* |
| Scanning Frequency | HDMI: 30 - 140 kHz (H) / 48-75 Hz (V); DP: 30 - 114 kHz (H) / 48-75 Hz (V); USB-C: 30 - 114 kHz (H) / 30-75 Hz (V) |
| sRGB | Yes |
| Delta E | < 2 |
| Flicker-free | Yes |
| Pixel Density | 109 PPI |
| LowBlue Mode | Yes |
| Display Screen Coating | Anti-Glare, 3H, Haze 25% |
| SmartUniformity | 93 ~ 105% |
| EasyRead | Yes |
| Adaptive sync (VRR) | Yes |
| HDR | DisplayHDR 400 certified |
| DICOM (D-mode) | Yes |
Connectivity
| Signal Input | HDMI 2.0 x 2, DisplayPort 1.4 x 1, USB-C x 1 (upstream, DP Alt mode, Data, PD up to 100W) |
| Sync Input | Separate Sync |
| Audio (In/Out) | Audio out / Microphone in combo jack |
| RJ45 | Ethernet LAN (USB 2.0: 10M/100M; USB 3.0: 1000M), PXE/MAPT/WOL* |
| HDCP | HDCP 1.4 (HDMI / DisplayPort / USB-C), HDCP 2.2 (HDMI / DisplayPort / USB-C) |
| HBR3 | HBR3 (USB-C / DisplayPort) |
| USB Hub | USB 3.2 Gen 1 / 5 Gbps, USB-B upstream x 1, USB-A downstream x 2 (with 1 for fast charge B.C 1.2), USB-C downstream x 1 (Data, PD 15W) |
Power Delivery
| Max power delivery | Up to 100 W* (5V/3A, 7V/3A, 9V/3A, 10V/3A, 12V/3A, 15V/3A, 20V/4.8A) |
| Version | USB PD version 3.0 |
Convenience
| Built-in Speakers | 3 W x 2 |
| Plug & Play Compatibility | DDC/CI, Mac OS, sRGB, Windows 11 / 10 / 8.1 / 8 |
| User convenience | Mic, SmartImage, Input, User, Menu, Power On/Off |
| Other convenience | Kensington lock, Earphone hook, VESA mount (100x100mm) |
| Control software | SmartControl, SmartManagement |
| MultiView | PIP/PBP mode, 2x devices |
| Built-in webcam | Pop-up 5.0 megapixel camera with microphone and LED indicator (for Windows Hello) |
| FocusSync light | Yes |
| KVM | Yes (USB-C/USB-B) |
| SmartKVM | Yes |
Stand
| Height adjustment | 150 mm |
| Swivel | -/+30 |
| Tilt | -5/15 |
Power
| ECO mode | 39 W (typ.) |
| Power supply | Built-in, 100-240VAC, 50-60Hz |
| Off mode | 0.3 W (typ.) |
| On mode | 46.1 W (typ.) (EnergyStar test method) |
| Standby mode | 0.3 W (typ.) |
| Power LED indicator | Operation - White, Standby mode- White (blinking) |
Dimensions
| Packaging in mm (WxHxD) | 1290 x 300 x 475 mm |
| Product without stand (mm) | 1193 x 373 x 164 mm |
| Product with stand(max height) | 1193 x 583 x 268 mm |
Weight
| Product with packaging (kg) | 19.38 kg |
| Product with stand (kg) | 15.21 kg |
| Product without stand (kg) | 11.58 kg |
Operating conditions
| Altitude | Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m) |
| Temperature range (operation) | 0°C to 40°C |
| Relative humidity | 20%-80% |
| Temperature range (storage) | -20°C to 60°C |
| MTBF (demonstrated) | 70,000 hrs (excluded backlight) |
Compliance and standards
| Regulatory Approvals | CB, CE Mark, FCC Class B, ICES-003, CU-EAC, EAEU RoHS, TUV Ergo, TUV/GS, eyesafe® CERTIFIED 2.0, cETLus, TÜV Rheinland Low Blue Light (Hardware Solution) |
Cabinet
| Finish | Texture |
| Foot | Silver |
| Front bezel | Charcoal |
| Rear cover | Charcoal |
* Values marked with an asterisk carry footnotes on the Philips datasheet (e.g. overclock or measurement conditions) — see the Philips leaflet for details.
Compatibility & Connectivity
Video Inputs
HDMI 2.0 x 2, DisplayPort 1.4 x 1, USB-C x 1 (upstream, DP Alt mode, Data, PD up to 100W). Connect a desktop PC, laptop or docking station with a matching cable.
USB-C Laptops
One USB-C cable carries video (DisplayPort Alt Mode), USB data and up to 100 W charging to a USB-C laptop. The laptop's USB-C port must support DisplayPort Alt Mode for video.
Operating Systems
Plug & Play: DDC/CI, Mac OS, sRGB, Windows 11 / 10 / 8.1 / 8.
Software
SmartControl, SmartManagement lets you adjust picture and monitor settings from your PC.
Mounting
VESA 100x100mm mount compatible for monitor arms and wall brackets.
Package Contents & Philips B Line Business Monitors Ordering Information
In the Box
49B2U5900CH monitor with stand, power cable, signal cable and quick start guide. Cable types vary by Philips Singapore pack — email us to confirm before ordering.
Philips B Line Business Monitors
| Model | Key feature |
| 24B2N2200G | 23.8" FHD IPS 144 Hz, VGA/HDMI/DP |
| 24B2N3200J | 23.8" FHD IPS 120 Hz, USB hub, pivot |
| 24B2U3301 | 23.8" FHD IPS 120 Hz, USB-C 90 W |
| 24B2U3601 | 23.8" QHD IPS 120 Hz, USB-C 90 W |
| 27B2N2200G | 27" FHD IPS 144 Hz, VGA/HDMI/DP |
| 27B2N3500J | 27" QHD IPS 120 Hz, USB hub, pivot |
| 27B2N3500G | 27" QHD IPS 144 Hz, USB hub, pivot |
| 27B2U3601 | 27" QHD IPS 120 Hz, USB-C 90 W dock, LAN |
| 27B1U3900 | 27" 4K UHD IPS, USB-C 90 W dock, LAN |
| 32B2U3601 | 31.5" QHD IPS 100 Hz, USB-C 90 W dock, LAN |
| 32B1U3900 | 31.5" 4K UHD VA, USB-C 90 W dock, LAN |
| 34B2U3600C | 34" WQHD 120 Hz curved, USB-C 90 W dock |
| 34B1U5600CH | 34" WQHD 120 Hz curved, USB-C 100 W, webcam |
| 34B2U5900C | 34" 5120x2160 120 Hz curved, USB-C 140 W |
| 49B2U5900CH (this listing) | 48.8" 5120x1440 curved, USB-C 100 W, webcam |
Datasheet & Downloads
| Philips product page | 49B2U5900CH on philips.com.sg |
| Product leaflet | 49B2U5900CH Leaflet (PDF) |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting 49B2U5900CH.
Frequently Asked Questions — Philips 49B2U5900CH
What resolution and refresh rate does the 49B2U5900CH support?
5120 x 1440 @ 75 Hz (per Philips specification).
Can it charge my laptop?
Yes, the USB-C port supplies up to 100 W, enough for most USB-C laptops; check your laptop's charging requirement.
Is the stand adjustable?
Yes: height adjustment 150 mm, swivel -/+30, tilt -5/15.
Does it have built-in speakers?
Yes, 3 W x 2.
What warranty do I get?
3 years on-site warranty in Singapore, serviced by Philips. Pixel policy: more than 2 dead/bright pixels in year 1, more than 3 from year 2. Supplied by SourceIT with a GST invoice.
