Philips 32" 4K UHD VA USB-C Docking Monitor with 90W Charging & LAN
PRODUCT DESCRIPTION
Philips 32B1U3900 32" 4K UHD VA USB-C Docking Monitor with 90W Charging & LAN - 3 Years On-site Warranty
VA display
VA display delivers awesome images with wide viewing angles.
10-bit colors
1.074 billion colors for smooth color gradations and detail.
UltraClear 4K UHD Resolution
UltraClear 4K UHD (3840x2160) resolution for precision.
SmartImage
SmartImage presets for easy optimized image settings.
Need monitors for a whole office, classroom or gaming room? Email sales@sourceit.com.sg for volume pricing and delivery lead time.
Philips 32B1U3900 Datasheet — Technical Specifications
General
| Product Name | Philips 32" 4K UHD VA USB-C Docking Monitor with 90W Charging & LAN |
| Model | 32B1U3900 (Philips CTN 32B1U3900/69) |
| Brand / Series | Philips monitors |
| Local Warranty (Singapore) | 3 years on-site warranty |
| Pixel Defect Policy | Replacement if more than 2 dead/bright pixels in year 1, or more than 3 from year 2 onwards |
Picture/Display
| Panel Size | 31.5"/80cm |
| Aspect ratio | 16:9 |
| LCD panel type | VA LCD |
| Backlight type | W-LED system |
| Pixel pitch | 0.18159 ×0.18159 mm |
| Brightness | 350 cd/m² |
| Display colors | 1.07B (10 bits)* |
| Color gamut (typical) | sRGB 122%, NTSC 106 %* |
| Contrast ratio (typical) | 3500:1 |
| SmartContrast | 50,000,000:1 |
| Response time (typical) | 4 ms (Gray to Gray)* |
| Viewing angle | 178º (H) / 178º (V), @ C/R > 10 |
| Picture enhancement | SmartImage |
| Maximum resolution | 3840x2160@60Hz |
| Effective viewing area | 697.306 (H) x 392.234 (V)mm |
| Scanning Frequency | 30 - 140 kHz (H) /23 - 75 Hz (V) |
| sRGB | Yes |
| Flicker-free | Yes |
| Pixel Density | 140 PPI |
| LowBlue Mode | Yes |
| Display Screen Coating | Anti-Glare, 3H, Haze 25% |
| EasyRead | Yes |
Connectivity
| Signal Input | HDMI 2.0 x 2, DisplayPort 1.4 x 1, USB-C x 1 (upstream, DP Alt mode, Data, PD up to 90 W) |
| Sync Input | Separate Sync |
| Audio (In/Out) | Audio out |
| RJ45 | Ethernet LAN (USB 2.0: 10M/100M; USB 3.0: 1000M), PXE/MAPT/WOL* |
| HDCP | HDCP 1.4 (HDMI / DisplayPort / USB-C); HDCP 2.2 (HDMI / DisplayPort / USB-C) |
| USB Hub | USB3.2, Gen1, 5G; upstream: USB-C x1 ;downstream: USB-A x4 (with x1 fast charge B.C 1.2) |
Power Delivery
| Max power delivery | USB-C up to 90 W* (5V/3A, 7V/3A, 9V/3A, 10V/3A, 12V/3A, 15V/3A, 20V/4.5A) |
| Version | USB PD version 3.0 |
Convenience
| Built-in Speakers | 3 W x 2 |
| Plug & Play Compatibility | DDC/CI, Mac OS, sRGB, Windows 11 / 10 |
| User convenience | SmartImage, Input, Brightness, Menu, Power On/Off |
| Other convenience | Kensington lock, VESA mount (100x100mm) |
| Control software | SmartControl |
| MultiView | PIP/PBP mode, 2x devices |
Stand
| Pivot | -/+90 degree |
| Height adjustment | 180 mm |
| Swivel | -/+180 |
| Tilt | -5/25 |
Power
| ECO mode | 20.4 W (typ.) |
| Power supply | Built-in, 100-240VAC, 50-60Hz |
| Off mode | 0.3 W (typ.) |
| On mode | 34.8 W (typ.) |
| Standby mode | 0.3 W (typ.) |
| Power LED indicator | Operation - White, Standby mode- White (blinking) |
Dimensions
| Packaging in mm (WxHxD) | 930 x 563 x 186 mm |
| Product without stand (mm) | 714 x 422 x 62 mm |
| Product with stand(max height) | 714 x 631 x 280 mm |
Weight
| Product with packaging (kg) | 16.23 kg |
| Product with stand (kg) | 11.47 kg |
| Product without stand (kg) | 7.56 kg |
Operating conditions
| Altitude | Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m) |
| Temperature range (operation) | 0°C to 40°C |
| Relative humidity | 20%-80% |
| Temperature range (storage) | -20°C to 60°C |
| MTBF (demonstrated) | 70,000 hrs (excluded backlight) |
Compliance and standards
| Regulatory Approvals | CB, CE Mark, TUV/GS, TUV Ergo, EAC, EAEU RoHS, MEPS, UKCA, EMF, FCC, ICES-003 |
Cabinet
| Finish | Texture |
| Foot | Black/Black |
| Front bezel | Black/Black |
| Rear cover | Black/Black |
* Values marked with an asterisk carry footnotes on the Philips datasheet (e.g. overclock or measurement conditions) — see the Philips leaflet for details.
Compatibility & Connectivity
Video Inputs
HDMI 2.0 x 2, DisplayPort 1.4 x 1, USB-C x 1 (upstream, DP Alt mode, Data, PD up to 90 W). Connect a desktop PC, laptop or docking station with a matching cable.
USB-C Laptops
One USB-C cable carries video (DisplayPort Alt Mode), USB data and up to 90 W charging to a USB-C laptop. The laptop's USB-C port must support DisplayPort Alt Mode for video.
Operating Systems
Plug & Play: DDC/CI, Mac OS, sRGB, Windows 11 / 10.
Software
SmartControl lets you adjust picture and monitor settings from your PC.
Mounting
VESA 100x100mm mount compatible for monitor arms and wall brackets.
Package Contents & Philips B Line Business Monitors Ordering Information
In the Box
32B1U3900 monitor with stand, power cable, HDMI cable, DisplayPort cable, USB-C to USB-C cable, quick start guide.
Philips B Line Business Monitors
| Model | Key feature |
| 24B2N2200G | 23.8" FHD IPS 144 Hz, VGA/HDMI/DP |
| 24B2N3200J | 23.8" FHD IPS 120 Hz, USB hub, pivot |
| 24B2U3301 | 23.8" FHD IPS 120 Hz, USB-C 90 W |
| 24B2U3601 | 23.8" QHD IPS 120 Hz, USB-C 90 W |
| 27B2N2200G | 27" FHD IPS 144 Hz, VGA/HDMI/DP |
| 27B2N3500J | 27" QHD IPS 120 Hz, USB hub, pivot |
| 27B2N3500G | 27" QHD IPS 144 Hz, USB hub, pivot |
| 27B2U3601 | 27" QHD IPS 120 Hz, USB-C 90 W dock, LAN |
| 27B1U3900 | 27" 4K UHD IPS, USB-C 90 W dock, LAN |
| 32B2U3601 | 31.5" QHD IPS 100 Hz, USB-C 90 W dock, LAN |
| 32B1U3900 (this listing) | 31.5" 4K UHD VA, USB-C 90 W dock, LAN |
| 34B2U3600C | 34" WQHD 120 Hz curved, USB-C 90 W dock |
| 34B1U5600CH | 34" WQHD 120 Hz curved, USB-C 100 W, webcam |
| 34B2U5900C | 34" 5120x2160 120 Hz curved, USB-C 140 W |
| 49B2U5900CH | 48.8" 5120x1440 curved, USB-C 100 W, webcam |
Datasheet & Downloads
| Philips product page | 32B1U3900 on philips.com.sg |
| Product leaflet | 32B1U3900 Leaflet (PDF) |
| User manual | 32B1U3900 User Manual (PDF, English) |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting 32B1U3900.
Frequently Asked Questions — Philips 32B1U3900
What resolution and refresh rate does the 32B1U3900 support?
3840x2160@60Hz (per Philips specification).
Can it charge my laptop?
Yes, the USB-C port supplies up to 90 W, enough for most USB-C laptops; check your laptop's charging requirement.
Is the stand adjustable?
Yes: height adjustment 180 mm, pivot -/+90 degree, swivel -/+180, tilt -5/25.
Does it have built-in speakers?
Yes, 3 W x 2.
What warranty do I get?
3 years on-site warranty in Singapore, serviced by Philips. Pixel policy: more than 2 dead/bright pixels in year 1, more than 3 from year 2. Supplied by SourceIT with a GST invoice.
