Philips 27" Full HD IPS Monitor with Height-Adjust & Pivot Stand
PRODUCT DESCRIPTION
Philips 272S1AE 27" Full HD IPS Monitor with Height-Adjust & Pivot Stand - 3 Years On-site Warranty
Built-in speakers
Built-in speakers for audio without desktop clutter.
SmartErgoBase
SmartErgoBase enables people-friendly ergonomic adjustments.
SmartImage
SmartImage presets for easy optimized image settings.
Adaptive-Sync technology
Effortlessly smooth action with Adaptive-Sync technology.
Need monitors for a whole office, classroom or gaming room? Email sales@sourceit.com.sg for volume pricing and delivery lead time.
Philips 272S1AE Datasheet — Technical Specifications
General
| Product Name | Philips 27" Full HD IPS Monitor with Height-Adjust & Pivot Stand |
| Model | 272S1AE (Philips CTN 272S1AE/69) |
| Brand / Series | Philips monitors |
| Local Warranty (Singapore) | 3 years on-site warranty |
| Pixel Defect Policy | Replacement if more than 2 dead/bright pixels in year 1, or more than 3 from year 2 onwards |
Picture/Display
| Panel Size | 27 inch / 68.6 cm |
| Aspect ratio | 16:9 |
| LCD panel type | IPS technology |
| Backlight type | W-LED system |
| Pixel pitch | 0.3114 x 0.3114 mm |
| Brightness | 250 cd/m² |
| Display colors | 16.7M |
| Color gamut (typical) | NTSC 81%*, sRGB 102%* |
| Contrast ratio (typical) | 1000:1 |
| SmartContrast | 50,000,000:1 |
| Response time (typical) | 4 ms (Gray to Gray)* |
| Viewing angle | 178º (H) / 178º (V), @ C/R > 10 |
| Picture enhancement | SmartImage |
| Maximum resolution | 1920 x 1080 @ 75 Hz* |
| Effective viewing area | 597.888 (H) x 336.312 (V) |
| Scanning Frequency | 30 - 85 kHz (H) / 48 - 75 Hz (V) |
| sRGB | Yes |
| Flicker-free | Yes |
| Pixel Density | 82 PPI |
| LowBlue Mode | Yes |
| Display Screen Coating | Anti-Glare, 3H, Haze 25% |
| EasyRead | Yes |
| Adaptive sync (VRR) | Yes |
Connectivity
| Signal Input | VGA (Analog), DVI-D (digital, HDCP), DisplayPort 1.2, HDMI 1.4 |
| Sync Input | Separate Sync, Sync on Green |
| Audio (In/Out) | PC audio-in, Headphone out |
| HDCP | HDCP 1.4 (DVI/DP/HDMI) |
Convenience
| Built-in Speakers | 2 W x 2 |
| Plug & Play Compatibility | DDC/CI, Mac OS X, sRGB, Windows 10 / 8.1 / 8 / 7 |
| User convenience | SmartImage, Input, Brightness, Menu, Power On/Off |
| Other convenience | Kensington lock, VESA mount (100x100mm) |
| Control software | SmartControl |
Stand
| Height adjustment | 130 mm |
| Pivot | -/+ 90 degree |
| Swivel | -/+ 180 degree |
| Tilt | -5 ~ 25 degree |
Power
| ECO mode | 11.5 W (typ.) |
| Power supply | Built-in, 100-240VAC, 50-60Hz |
| Off mode | 0.2 W (typ.) |
| On mode | 16.3 W (typ.) (EnergyStar test method) |
| Standby mode | 0.3 W (typ.) |
| Power LED indicator | Operation - White, Standby mode- White (blinking) |
Dimensions
| Packaging in mm (WxHxD) | 700 x 456 x 215 mm |
| Product without stand (mm) | 613 x 366 x 51 mm |
| Product with stand(max height) | 613 x 537 x 205 mm |
Weight
| Product with packaging (kg) | 9.38 kg |
| Product with stand (kg) | 6.00 kg |
| Product without stand (kg) | 4.13 kg |
Operating conditions
| Altitude | Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m) |
| Temperature range (operation) | 0°C to 40°C |
| Relative humidity | 20%-80% |
| Temperature range (storage) | -20°C to 60°C |
| MTBF (demonstrated) | 70,000 hrs (excluded backlight) |
Compliance and standards
| Regulatory Approvals | CB, EPA, FCC Class B, ICES-003, CE Mark, TUV/GS, TUV Ergo, SEMKO, CU-EAC, TUV Eye Comfort certified, PSB |
Cabinet
| Finish | Texture |
| Foot | Black |
| Front bezel | Black |
| Rear cover | Black |
* Values marked with an asterisk carry footnotes on the Philips datasheet (e.g. overclock or measurement conditions) — see the Philips leaflet for details.
Compatibility & Connectivity
Video Inputs
VGA (Analog), DVI-D (digital, HDCP), DisplayPort 1.2, HDMI 1.4. Connect a desktop PC, laptop or docking station with a matching cable.
Operating Systems
Plug & Play: DDC/CI, Mac OS X, sRGB, Windows 10 / 8.1 / 8 / 7.
Software
SmartControl lets you adjust picture and monitor settings from your PC.
Mounting
VESA 100x100mm mount compatible for monitor arms and wall brackets.
Package Contents & Philips S Line, Touch & Large-Format Monitors Ordering Information
In the Box
272S1AE monitor with stand, power cable, HDMI cable, DisplayPort cable, quick start guide.
Philips S Line, Touch & Large-Format Monitors
| Model | Key feature |
| 170S9A | 17" 5:4 SXGA, VGA/DVI, speakers |
| 19S4QAB | 19" 5:4 SXGA IPS, VGA/DVI, speakers |
| 243S9A | 23.8" FHD IPS, USB-C 65 W, USB hub |
| 242B9T | 23.8" FHD IPS 10-point touch |
| 272S1AE (this listing) | 27" FHD IPS 75 Hz, pivot stand |
| 438P1 | 42.5" 4K UHD IPS, MultiView |
Datasheet & Downloads
| Philips product page | 272S1AE on philips.com.sg |
| Product leaflet | 272S1AE Leaflet (PDF) |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting 272S1AE.
Frequently Asked Questions — Philips 272S1AE
What resolution and refresh rate does the 272S1AE support?
1920 x 1080 @ 75 Hz (per Philips specification).
Can it charge a laptop?
No, this model has no USB-C power delivery; use your laptop's own charger.
Is the stand adjustable?
Yes: height adjustment 130 mm, pivot -/+ 90 degree, swivel -/+ 180 degree, tilt -5 ~ 25 degree.
Does it have built-in speakers?
Yes, 2 W x 2.
What warranty do I get?
3 years on-site warranty in Singapore, serviced by Philips. Pixel policy: more than 2 dead/bright pixels in year 1, more than 3 from year 2. Supplied by SourceIT with a GST invoice.
