OKI Pro9541dn SRA3 5-Colour LED Printer, CMYK + Spot White or Clear, 50ppm
PRODUCT DESCRIPTION
OKI Pro9541dn SRA3 5-Colour LED Printer, CMYK + Spot White or Clear, 50ppm (46220201) - Local Warranty
The OKI Pro9541dn is an SRA3 five-colour LED printer that adds a fifth spot colour (white or clear, via OKI Spot Color Kits) to CMYK. It is rated at 50 ppm A4 and 28 ppm A3 in colour and mono, with 1200 x 1200 dpi output.
CMYK plus a fifth spot colour
Prints in full-range process CMYK plus a spot colour in white or clear gloss for high-quality, on-demand printing.
Exceptional quality
Superb 1200 x 1200dpi print resolution with Multi-Level ProQ technology to enhance colour print output.
Media flexibility
Paper sizes from A6 to SRA3 and banner lengths up to 1.3m; prints on stock up to 360gsm single-sided and 320gsm duplex.
Grow margins in-house
Print in all colours including solid white or clear gloss quickly and cost effectively for proofing concepts or short print run materials.
Cost efficiency
Ultra-high capacity toner cartridges (up to 51K) and drums, with separate toners and drums for reduced wastage.
Ideal For
Print service providers and creative studios in Singapore adding value with white underprints on dark or clear media, or clear-toner highlights, in-house and on demand. Supplied by SourceIT with local Singapore warranty, GST invoice and corporate or project pricing on request.
OKI Pro9541dn Datasheet — Technical Specifications
General
| Model | Pro9541dn |
| Official Product Name | OKI Pro9541dn |
| OKI Part Number | 46220201 |
| Brand | OKI |
| Warranty | Local Warranty (Singapore) - OKI Singapore standard warranty terms apply; please confirm the coverage period with SourceIT before ordering |
| Printing Method | Digital 5 LED Full-color Electrophotographic Printing Method |
| Printing Resolution | 1200 x 1200 dpi (2 levels), 1200 x 600 dpi (16 levels), 600 x 600 dpi (2 levels), Physical dot pitch: 1200 dpi |
| Warm-up Time | Approx. 50.0 seconds from power-on; Approx. 35.0 seconds from power save |
| First Print Out Time | Color: Approx. 8.0 seconds; Mono: Approx. 8.0 seconds |
| Print Speed | A4(Landscape) 50 ppm color, 50 ppm mono; A3 28 ppm color, 28 ppm mono |
| Printer Language | Adobe PostScript 3, PCL 5c emulation, PCL 6 (XL) emulation, XPS emulation, PDF v1.7 emulation, IBM ProPrinter emulation, Epson FX Emulation |
| Font | Adobe PostScript 136 fonts, PCL emulation 87 scalable fonts, 4 bitmap fonts |
| Memory (Std./Max.) | 2GB/2GB |
| Hard Disk Drive | (Optional) 160 GB |
Paper Handling
| Paper Size | SRA3, SRA4, A3+, A3, A4, A5, A6, B5, B4, Tabloid extra (12" x 18"), Tabloid (11" x 17"), Legal 13, Legal 13.5, Legal 14, Letter, Executive, Index Card (3" x 5") (75 x 125mm), Statement, Envelopes, Postcard, Return postcard, Banner, B6 Half, B4, 8K, 16K, Custom Size: Width 64-330 mm x Length 89-1321 mm |
| Paper Weight | Tray 1: 52 - 320 gsm; (Optional) Additional Tray: 52 - 320 gsm; Multi-purpose tray: 52 - 360 gsm |
| Input Capacity | Tray 1: 530 sheets; (Optional) Additional Tray: 530 sheets; Multi-purpose tray: 300 sheets |
| Output Capacity | Face Down: Max. 610 sheets; Face Up: Max. 300 sheets |
Connectivity & Software
| Interface | 1000BASE-T/100BASE-TX/10BASE-T, USB 2.0 (High Speed) |
| Protocol | TCP/IP, EtherTalk |
| Supported OS | Windows 10, Windows 10 x64, Windows 8.1, Windows 8.1 x64, Windows 8, Windows 8 x64, Windows 7, Windows 7 x64, Windows Vista, Windows Vista x64, Windows XP, Windows XP x64, Windows Server 2012 R2, Windows Server 2012, Windows Server 2008 R2, Windows Server 2008, Windows Server 2008 x64, OS X 10.10, OS X 10.9, OS X 10.8, OS X 10.7, Mac OS X 10.6, Mac OS X 10.5, Linux |
Physical & Power
| Dimensions(WxDxH) | 699 x 625 x 640 mm |
| Weight(includes supplies) | Approx. 116.5 kg |
| Weight(not includes supplies) | Approx. 91.0 kg |
| Power Source | Single phase 230 VAC ±10%, 50/60 Hz ±2% |
| Power Consumption | Operating: Max. 1,600W / Ave. 1,100W; Idle: 40W; Power Save: 34.0W; Deep Sleep: 4.0W; Auto-Off: 0.5W |
| Noise Level | Operating: Approx. 57 dBA; Idle: < 34 dBA; Power Save: < 30 dBA or Background level |
| Operating Environment | Operating: 10 - 32 °C, 20 - 80 %RH, No condensation |
General
| Duty Cycle | Recommended: 25,000 pages/month; Maximum: 300,000 pages/month |
Compatibility & Software Support
Compatibility details below are taken from OKI Singapore's published specification for the OKI Pro9541dn. Drivers, utilities and firmware are available from OKI Singapore's support site (see Datasheet & Downloads).
| Interface | 1000BASE-T/100BASE-TX/10BASE-T, USB 2.0 (High Speed) |
| Protocol | TCP/IP, EtherTalk |
| Supported OS | Windows 10, Windows 10 x64, Windows 8.1, Windows 8.1 x64, Windows 8, Windows 8 x64, Windows 7, Windows 7 x64, Windows Vista, Windows Vista x64, Windows XP, Windows XP x64, Windows Server 2012 R2, Windows Server 2012, Windows Server 2008 R2, Windows Server 2008, Windows Server 2008 x64, OS X 10.10, OS X 10.9, OS X 10.8, OS X 10.7, Mac OS X 10.6, Mac OS X 10.5, Linux |
Package Contents & Ordering Information
In the Box
- Manuals
- Power cable
- DVD-ROM
- Starter toner cartridge x 4
- Image Drum x 4
Ordering Information
| Model | Pro9541dn |
| OKI Part Number | 46220201 |
| Recommended Retail Price (incl. GST) | S$12,983.10 |
Optional Accessories
- Additional Paper Tray (530 sheets of 80gsm) - 45530703
- Large Capacity Feeder (1,590 sheets of 80gsm) - 45530803
- 160 GB Hard Disk Drive - 44622302
- Spot Color Kit (White) - 45531313
- Spot Color Kit (Clear) - 45531413
- Additional paper tray with castor (530 sheets of 80gsm) - 45530903
Consumables
- White Toner cartridge (10,000 pages) - 45536459
- Clear Large capacity toner cartridge (20,000 pages) - 45536460
- Black Ultra-high capacity print cartridge (51,000 pages) - 45536573
- Yellow Ultra-high capacity print cartridge (42,000 pages) - 45536570
- Magenta Ultra-high capacity print cartridge (42,000 pages) - 45536571
- Cyan Ultra-high capacity print cartridge (42,000 pages) - 45536572
- Black Image Drum (40,000 pages) - 45103740
- Yellow Image Drum (40,000 pages) - 45103737
- Magenta Image Drum (40,000 pages) - 45103738
- Cyan Image Drum (40,000 pages) - 45103739
- White Image Drum (20,000 pages) - 45103743
- Clear Image Drum (20,000 pages) - 45103744
- Fuser unit (150,000 pages) - 45531113
- Transfer Belt (150,000 pages) - 45531223
- Waste toner box (40,000 pages) - 45531503
Options and consumables are sold separately. Page yields are OKI figures. Ask SourceIT to quote the printer together with trays, toner and drums.
Datasheet & Downloads
Frequently Asked Questions — OKI Pro9541dn
What warranty does the OKI Pro9541dn come with?
The printer is covered by OKI Singapore's standard local warranty. OKI Singapore does not state the coverage period on the product page, so please ask SourceIT to confirm the warranty term and service arrangement before ordering. Every unit sold by SourceIT is a genuine Singapore set with a GST invoice.
Which consumables does the OKI Pro9541dn use?
OKI lists: White Toner cartridge (10,000 pages) - 45536459; Clear Large capacity toner cartridge (20,000 pages) - 45536460; Black Ultra-high capacity print cartridge (51,000 pages) - 45536573; Yellow Ultra-high capacity print cartridge (42,000 pages) - 45536570; Magenta Ultra-high capacity print cartridge (42,000 pages) - 45536571; Cyan Ultra-high capacity print cartridge (42,000 pages) - 45536572. Always use genuine OKI consumables to protect print quality and warranty coverage. SourceIT can supply them together with the printer.
How does the OKI Pro9541dn connect?
OKI specifies: 1000BASE-T/100BASE-TX/10BASE-T, USB 2.0 (High Speed).
Is stock held locally?
Anything not in local stock is ordered through OKI Data (Singapore). Ask us for the current lead time before committing to a date.
Can SourceIT quote for multiple units or a project?
Yes. Send us your quantity and delivery requirements and we will quote the printers together with options and consumables, with local warranty and GST invoice.
