OKI C834nw A3 Colour LED Printer, 36ppm, Gigabit Network, Wi-Fi
PRODUCT DESCRIPTION
OKI C834nw A3 Colour LED Printer, 36ppm, Gigabit Network, Wi-Fi (47074215) - Local Warranty
The OKI C834nw is a compact A3 colour LED printer rated at 36 ppm A4 and 20 ppm A3 in colour and mono, with Gigabit Ethernet, built-in Wireless LAN (IEEE 802.11a/b/g/n) and USB 2.0. Duplex printing and additional paper trays are available as options.
Super compact
OKI describes the C800 Series as the smallest A3 colour printer on the market, so it fits on a desk.
Eco-friendly Performance
Energy and time-saving with efficient fusing technology
Media Handling
Print in sizes and weights up to 256gsm and banners up to 1.3m
Easy printing on the go
Tap-and-print NFC functionality and Apple AirPrint support for printing from mobile devices.
Ideal For
Offices, schools and design studios in Singapore that need A3 colour output (posters, drawings, spreadsheets, banners) from a printer small enough to sit on a desk. Supplied by SourceIT with local Singapore warranty, GST invoice and corporate or project pricing on request.
OKI C834nw Datasheet — Technical Specifications
General
| Model | C834nw |
| Official Product Name | OKI C834nw |
| OKI Part Number | 47074215 |
| Brand | OKI |
| Warranty | Local Warranty (Singapore) - OKI Singapore standard warranty terms apply; please confirm the coverage period with SourceIT before ordering |
| Printing Method | Digital 4 LED Full-color Electrophotographic Printing Method |
| Printing Resolution | 600 x 600 dpi, 600 x 1200 dpi, 600 x 600 dpi (4 levels), Physical dot pitch: 600 dpi |
| Warm-up Time | Approx. 20.0 seconds from power-on, Approx. 9.9 seconds from power save |
| First Print Out Time | Color: Approx. 6.3 seconds, Mono: Approx. 6.3 seconds |
| Print Speed | A4(Landscape) 36 ppm color, 36 ppm mono, A3 20 ppm color, 20 ppm mono |
| Printer Language | PCL 6 (XL) emulation, PCL 5c emulation, Epson FX Emulation, PostScript 3 emulation, PDF v1.7 emulation, IBM ProPrinter emulation |
| Font | PCL emulation 87 scalable fonts, 4 bitmap fonts; PostScript emulation 80 fonts |
| Memory (Std./Max.) | 1GB/1GB |
| Duty Cycle | Recommended: 10,000 pages/month, Maximum: 50,000 pages/month |
Paper Handling
| Paper Size | A3, A4, A5, A6, B4, B5, B6, B6 Half, Legal 13, Legal 13.5, Legal 14, Tabloid (11" x 17"), Letter, Executive, 16K, 8K, Statement, Folio, Banner, Envelopes, Postcard, Return postcard, Index Card (3" x 5") (75 x 125mm), Photo Size (4" x 6", 5" x 7") (100 x 150mm, 125 x 175mm), Custom Size: Width 55-297 mm x Length 90-1321 mm, B8, B7 |
| Paper Weight | Tray 1: 64-220 gsm, Multi-purpose tray: 64-256 gsm, (Optional) Additional Tray: 64-176 gsm |
| Input Capacity | Tray 1: 300 sheets, Multi-purpose tray: 100 sheets, (Optional) Additional Tray: 535 sheets |
| Output Capacity | Face Down: Max. 250 sheets, Face Up: Max. 100 sheets |
Connectivity & Software
| Interface | 1000BASE-T/100BASE-TX/10BASE-T, Wireless LAN (IEEE802.11a/b/g/n), USB 2.0 (High Speed) |
| Protocol | TCP/IP |
| Supported OS | Windows 10/10 x64, Windows 8.1/8.1 x64, Windows 8/8 x64, Windows 7/7 x64, Windows Server 2016/2012 R2/2012/2008 R2/2008/2008 x64, macOS 10.13/10.12, OS X 10.11/10.10, iOS, Linux, Android |
Physical & Power
| Dimensions (WxDxH) | 449 x 552 x 360 mm |
| Weight (includes supplies) | Approx. 37.0 kg |
| Power Consumption | Operating: Max. 1,400W / Ave. 680W, Idle: 13W, Power Save: 11.0W, Deep Sleep: 1.0W, Auto-Off: 0.15W |
| Noise Level | Operating: Approx. 54 dBA, Idle: < 32 dBA |
General
| Operating Environment | Operating: 10-32 °C, 20-80 %RH, No condensation |
| Safety & Environment Regulation | CE Mark, GS Mark |
Compatibility & Software Support
Compatibility details below are taken from OKI Singapore's published specification for the OKI C834nw. Drivers, utilities and firmware are available from OKI Singapore's support site (see Datasheet & Downloads).
| Interface | 1000BASE-T/100BASE-TX/10BASE-T, Wireless LAN (IEEE802.11a/b/g/n), USB 2.0 (High Speed) |
| Protocol | TCP/IP |
| Supported OS | Windows 10/10 x64, Windows 8.1/8.1 x64, Windows 8/8 x64, Windows 7/7 x64, Windows Server 2016/2012 R2/2012/2008 R2/2008/2008 x64, macOS 10.13/10.12, OS X 10.11/10.10, iOS, Linux, Android |
Package Contents & Ordering Information
In the Box
- Starter toner cartridge x 4
- Image Drum x 4
- Power cable
- DVD-ROM
Ordering Information
| Model | C834nw |
| OKI Part Number | 47074215 |
| Recommended Retail Price (incl. GST) | S$2,955.64 |
Optional Accessories
- Additional Paper Tray (47074403) - 535 sheets of 80gsm
- Duplex unit (47079403)
- IC Card Holder (46539501)
- Castor base (45889502)
Consumables
- Black Large capacity toner cartridge (46861312) - 10,000 pages
- Yellow Large capacity toner cartridge (46861309) - 10,000 pages
- Magenta Large capacity toner cartridge (46861310) - 10,000 pages
- Cyan Large capacity toner cartridge (46861311) - 10,000 pages
- Black Image Drum (46857512) - 30,000 pages
- Yellow Image Drum (46857509) - 30,000 pages
- Magenta Image Drum (46857510) - 30,000 pages
- Cyan Image Drum (46857511) - 30,000 pages
- Fuser unit (47219604) - 100,000 pages
- Transfer Belt (47074503) - 80,000 pages
Options and consumables are sold separately. Page yields are OKI figures. Ask SourceIT to quote the printer together with trays, toner and drums.
Datasheet & Downloads
Frequently Asked Questions — OKI C834nw
What warranty does the OKI C834nw come with?
The printer is covered by OKI Singapore's standard local warranty. OKI Singapore does not state the coverage period on the product page, so please ask SourceIT to confirm the warranty term and service arrangement before ordering. Every unit sold by SourceIT is a genuine Singapore set with a GST invoice.
Which consumables does the OKI C834nw use?
OKI lists: Black Large capacity toner cartridge (46861312) - 10,000 pages; Yellow Large capacity toner cartridge (46861309) - 10,000 pages; Magenta Large capacity toner cartridge (46861310) - 10,000 pages; Cyan Large capacity toner cartridge (46861311) - 10,000 pages; Black Image Drum (46857512) - 30,000 pages; Yellow Image Drum (46857509) - 30,000 pages. Always use genuine OKI consumables to protect print quality and warranty coverage. SourceIT can supply them together with the printer.
How does the OKI C834nw connect?
OKI specifies: 1000BASE-T/100BASE-TX/10BASE-T, Wireless LAN (IEEE802.11a/b/g/n), USB 2.0 (High Speed).
Is stock held locally?
Anything not in local stock is ordered through OKI Data (Singapore). Ask us for the current lead time before committing to a date.
Can SourceIT quote for multiple units or a project?
Yes. Send us your quantity and delivery requirements and we will quote the printers together with options and consumables, with local warranty and GST invoice.
