MSI MAG 322URDF E16 31.5" 4K UHD 160Hz / Full HD 320Hz Dual-Mode Rapid IPS Gaming Monitor
PRODUCT DESCRIPTION
MSI MAG 322URDF E16 31.5" 4K UHD 160Hz / Full HD 320Hz Dual-Mode Rapid IPS Gaming Monitor
Key specifications: 31.5" · Dual-Mode FHD-320Hz & UHD-160Hz · Rapid IPS · 1ms(MPRT) · 0.5ms(GtG) · FreeSync Premium · HDR400 · Adjustable Stand · 2x HDMI2.1 · DP1.4a · USB Hub
Dual Mode
Dual Mode allows you to select the resolution and refresh rate that best suit your game, switching between UHD at 160Hz and FHD at 320Hz.
AI Navigator
AI Dual Mode, exclusively developed by MSI, is an AI-powered feature that detects the current resolution and adjusts automatically.
Console mode + HDMI™ 2.1
HDMI™ 2.1 provides full bandwidth up to 48Gbps, supporting VRR and ALLM.
Aspect Ratio Options
Supports a variety of aspect ratios, allowing for selection between 24.5" and 27" imagery.
Gaming Intelligence APP
With the Gaming Intelligence APP it is very easy to set up your gaming monitor.
Optix Scope
The built-in aim magnifier provides multi-stage zooming with shortcut keys.
MSI MAG 322URDF E16 Datasheet — Technical Specifications
General
| Product Name | MSI MAG 322URDF E16 31.5" 4K UHD 160Hz / Full HD 320Hz Dual-Mode Rapid IPS Gaming Monitor |
| Model | MAG 322URDF E16 |
| MSI Part Number | 9S6-3DD89T-001 |
| EAN | 4711377307383 |
| Brand / Series | MSI MAG / MPG Gaming Monitors |
Display
| Panel Size | 31.5" |
| Active Display Area (mm) | 695.04 (H) x 390.96 (V) |
| Curvature | Flat |
| Panel Type | Rapid IPS |
| Panel Resolution | Normal: 3840 x 2160 (UHD); Dual Mode: 1920 x 1080 (FHD) |
| Pixel Pitch (H x V) | 0.181 (H) x 0.181 (V) |
| Aspect Ratio | 16:9 |
| Brightness (nits) | SDR: 400 cd/m² (Typ.); HDR: 450 cd/m² (Peak) |
| Contrast Ratio | 1000:1 (Typ.) |
| DCR | 100000000:1 |
| Signal Frequency | Normal: 146.3~353.1KHz(H) / 48~160Hz(V); Dual Mode: 352.2~356.1KHz(H) / 48~320Hz(V) |
| Activated Range | Normal: 48~160Hz; Dual Mode: 48~320Hz |
| Refresh Rate | Normal: 160Hz; Dual Mode: 320Hz |
| Response time | 0.5ms (GtG, Min.) |
| Dynamic Refresh Rate Technology | AMD FreeSync™ Premium |
| HDR Support | VESA DisplayHDR 400 |
| Viewing Angle | 178° (H) / 178° (V) |
| Adobe RGB / DCI-P3 / sRGB | 93% / 99% / 131% (CIE1976 Standard) |
| Surface Treatment | Anti-glare |
| Display Colors | 1.07B, 10 bits (8 bits + FRC) |
Connectivity & Features
| Video ports | 1 x DisplayPort 1.4a (HBR3); 2 x HDMI™ 2.1 (4K@160Hz) |
| USB ports | 2 x USB 2.0 Type-A; 1 x USB 2.0 Type-B |
| Audio ports | 1x Headphone-out |
| Console Mode | Supported Resolution & Refresh Rate: 1080p: 60Hz and 120Hz; 1440p: 60Hz and 120Hz; 2160p: 60Hz and 120Hz; HDMI™ CEC: Supported; VRR: PS5 and Xbox Supported |
| Note | HDMI™: Normal (UHD) : 3840 x 2160 (Up to 160Hz); Dual (FHD) : 1920 x 1080 (Up to 320Hz); DisplayPort: Normal (UHD) : 3840 x 2160 (Up to 160Hz); Dual (FHD) : 1920 x 1080 (Up to 320Hz); Support: HDMI™ CEC, PIP/PBP; Non Support: KVM |
Ergonomics & Mounting
| Adjustment (Tilt) | -5° ~ 15° |
| Adjustment (Swivel) | -30° ~ 30° |
| Adjustment (Pivot) | -10° ~ 10° |
| Adjustment (Height) | 0~110 mm |
| Kensington Lock | Yes |
| VESA Mounting | 100 x 100 mm |
Power
| Power Type | Internal Power Board |
| Power Input | 100~240V, 50/60Hz |
Dimensions & Weight
| Dimension with Stand (W x D x H) | 714 x 261.9 x 564.5mm (28.1 x 8.9 x 22.2 inch) |
| Dimension without Stand (W x D x H) | 714 x 72.9 x 421.3mm (28.1 x 2.8 x 16.5 inch) |
| Weight (NW / GW) | 9 kg (19.8lbs) / 13 kg (28.6lbs) |
| Carton Dimension (W X D X H) | 985 x 183 x 513mm (38.7 x 7.2 x 20.1 inch) |
Certifications, Warranty & Accessories
| Accessories | 1x DisplayPort Cable (1.4a); 1x USB Type-B to A Cable; 1x Power Cord (C13); 1x Quick Guide; 4x Stand Screw |
Specifications are as published by MSI and may change without notice — see the MSI product page for the latest details.
Compatibility & Connectivity
Video Inputs
1 x DisplayPort 1.4a (HBR3); 2 x HDMI™ 2.1 (4K@160Hz)
USB
2 x USB 2.0 Type-A; 1 x USB 2.0 Type-B
Audio
1x Headphone-out
Supported Modes (MSI note)
HDMI™: Normal (UHD) : 3840 x 2160 (Up to 160Hz); Dual (FHD) : 1920 x 1080 (Up to 320Hz); DisplayPort: Normal (UHD) : 3840 x 2160 (Up to 160Hz); Dual (FHD) : 1920 x 1080 (Up to 320Hz); Support: HDMI™ CEC, PIP/PBP; Non Support: KVM
Console Mode
Supported Resolution & Refresh Rate: 1080p: 60Hz and 120Hz; 1440p: 60Hz and 120Hz; 2160p: 60Hz and 120Hz; HDMI™ CEC: Supported; VRR: PS5 and Xbox Supported
Mounting
VESA 100 x 100 mm — fits standard VESA monitor arms; check the arm's weight rating against the monitor weight in the datasheet.
Package Contents & MSI MAG / MPG Gaming Monitors Ordering Information
In the Box
1x DisplayPort Cable (1.4a); 1x USB Type-B to A Cable; 1x Power Cord (C13); 1x Quick Guide; 4x Stand Screw
MSI MAG / MPG Gaming Monitors
| Model | Key feature |
| MAG401QR | 40" / UWQHD / IPS / 155Hz / 1ms(MPRT) |
| MAG 342CQRF E20 | 34" / UWQHD / Curved 1500R / Rapid VA / 200Hz |
| MAG 325QF E18V | 31.5" / WQHD / Rapid VA / 180Hz / 1ms(MPRT) |
| MAG 321CQF E18 | 31.5" / WQHD / Curved 1500R / Rapid VA / 180Hz |
| MAG 322URDF E16 (this listing) | 31.5" / Dual-Mode FHD-320Hz & UHD-160Hz / Rapid IPS / 1ms(MPRT) / 0.5ms(GtG) |
| MAG 321CUPDF | 31.5" / Dual-Mode FHD-320Hz & UHD-160Hz / Curved 1500R / Rapid VA / 1ms(MPRT) |
| MAG 271KPD7 | 27" / Dual-Mode WQHD-300Hz & 5K UHD-75Hz / Rapid IPS / 0.5ms(MPRT) / 0.5ms(GtG) |
| MPG 274URDFW E16M | 27" / Dual-Mode FHD-320Hz & UHD-160Hz / Rapid IPS / Mini-LED / 1ms(MPRT) |
| MAG 274QPF X30MV | 27" / WQHD / Rapid VA / 300Hz / Mini-LED |
| MAG 275UPD E14 | 27" / Dual-Mode FHD-288Hz & UHD-144Hz / Rapid IPS / 1ms(MPRT) / 0.5ms(GtG) |
| MAG 274QRFW X32 | 27" / WQHD / Rapid IPS / 320Hz / 1ms(MPRT) |
| MAG 274QPF E20 | 27" / WQHD / Rapid IPS / 200Hz / 1ms(MPRT) |
| MAG 274QF X24 | 27" / WQHD / Rapid IPS / 240Hz / 1ms(MPRT) |
| MAG 274F | 27" / FHD / Rapid IPS / 200Hz / 1ms(MPRT) |
| MAG 255F X24 | 24.5" / FHD / Rapid IPS / 240Hz / 1ms(MPRT) |
Datasheet & Downloads
| MSI product page | MAG 322URDF E16 on msi.com |
| Specifications | MAG 322URDF E16 specifications |
| Drivers, manuals & firmware | MAG 322URDF E16 support |
Frequently Asked Questions — MSI MAG 322URDF E16
What resolution and refresh rate does the MAG 322URDF E16 support?
Resolution: Normal: 3840 x 2160 (UHD); Dual Mode: 1920 x 1080 (FHD). Refresh rate: Normal: 160Hz; Dual Mode: 320Hz (per MSI specification).
Can it charge a laptop?
No, this model has no USB-C power delivery; use your laptop's own charger.
Is the stand height-adjustable?
Yes — height 0~110 mm, tilt -5° ~ 15°, swivel -30° ~ 30°, pivot -10° ~ 10°.
Does it have built-in speakers?
No, connect headphones or external speakers.
What warranty do I get?
Singapore local MSI warranty through the authorised distributor. Supplied by SourceIT with a GST invoice.
