LG 98TR3DK-BM 98" CreateBoard Interactive Display, 4K UHD, 40-Point Touch, Android 13
PRODUCT DESCRIPTION
LG 98TR3DK-BM 98" CreateBoard 4K UHD Interactive Display (98TR3DK-BM) - 3 Years Local Warranty
98-Inch 4K Board for Lecture Halls and Large Rooms
The LG 98TR3DK-BM is the 98-inch CreateBoard in LG's TR3DK series. Its 3,840 x 2,160 IPS panel delivers 390 nit typical and 440 nit maximum brightness (measured without glass), and LG rates it for 16 hours a day, 7 days a week in landscape orientation.
Multi-User Touch Writing
LG specifies up to 40 touch points under Windows and 32 under Android, 5 ms or faster touch response and ±1.5 mm accuracy, behind 4 mm anti-glare protection glass with 88% transmission. Two writing pens are supplied.
Android 13 Built In
The embedded Android 13 system uses a quad-core A55 processor with Mali-G52 MP2 graphics, 8 GB RAM and 64 GB storage, with Wi-Fi 6, Bluetooth 5.0 and Gigabit LAN. Screen Share and PIP/PBP with external sources are listed by LG.
Connectivity and Management
Inputs include three HDMI (HDCP 2.2), VGA, four USB 3.0 and one USB 2.0 Type-A, plus a USB Type-C port with USB-PD and DP Alt Mode. An OPS slot with built-in power accepts an optional PC, and the display supports LG ConnectedCare and ConnectedCare DMS.
Need help planning a large-room CreateBoard installation? Email sales@sourceit.com.sg with the room size, mounting surface and how you plan to connect, and we will advise.
LG 98TR3DK-BM Datasheet — Technical Specifications
General
| Product Name | LG 98TR3DK-BM 98" CreateBoard |
| Part Number | 98TR3DK-BM |
| Series | TR3DK CreateBoard (Interactive Digital Board) |
| Local Warranty (Singapore) | 3 years on-site, supplied by SourceIT with a GST invoice |
Panel
| Screen Size | 98" |
| Panel Technology | IPS |
| Backlight | Direct |
| Native Resolution | 3,840 x 2,160 (4K UHD), 16:9, 60 Hz |
| Brightness | 390 nit typ., 440 nit max. (without glass) |
| Contrast Ratio | 1,200:1 |
| Colour Gamut | NTSC 72% |
| Colour Depth | 1.07 billion (10 bit) |
| Viewing Angle (H x V) | 178 x 178 |
| Response Time | 8 ms |
| Surface Treatment (Haze) | 25% |
| Lifetime | 30,000 hours (L50, min.); 50,000 hours (L30) |
| Operation Hours | 16 hours / 7 days |
| Portrait / Landscape | No / Yes |
Touch
| Multi-Touch Points | Max. 40 (Windows), max. 32 (Android) |
| Minimum Object Size | Ø2 mm and above |
| Touch Response Time | ≤5 ms |
| Accuracy | ±1.5 mm |
| Touch Interface | USB 2.0 |
| Protection Glass | 4 mm, anti-glare |
| Glass Transmission | 88% |
| Touch OS Support | Windows 7 / 8 / 10, Linux, Mac, Android |
Android System
| SoC | Quad-core A55 |
| GPU | Mali-G52 MP2 |
| RAM | 8 GB |
| Storage | 64 GB |
| Wi-Fi | 802.11 a/b/g/n/ac/ax (Wi-Fi 6) |
| LAN | Gigabit LAN |
| Bluetooth | Bluetooth 5.0 |
| OS | Android 13 |
Connectivity
| Inputs | HDMI x 3 (HDCP 2.2), RGB (VGA), Audio In, RS-232C In, RJ45 (LAN), USB 3.0 Type-A x 4, USB 2.0 Type-A x 1, USB Type-C x 1 (USB-PD, DP Alt Mode) |
| Outputs | HDMI Out, Audio Out (incl. optical SPDIF), Touch USB x 2, RJ45 (LAN) |
| Wireless | Wi-Fi 6 and Bluetooth 5.0 (built-in, slot type) |
| Speakers | 15 W x 2 |
| OPS | OPS slot compatible, OPS power built in |
Mechanical
| Bezel | Black; T / R / L / B 30 / 27 / 27 / 45 mm |
| Dimensions (W x H x D) | 2,244 x 1,323 x 91 mm |
| Weight (Head) | 103.6 kg |
| Carton Dimensions (W x H x D) | 2,406 x 1,474 x 280 mm |
| Packed Weight | 133.2 kg |
| Handle | Yes |
| VESA Mount | 800 x 600 mm |
Power & Environment
| Power Supply | AC 100–240 V, 50/60 Hz, built-in power |
| Power Consumption | 395 W typ. / 610 W max.; DPM ≤0.5 W; power off ≤0.5 W |
| Heat Dissipation | 1,348 BTU/hr (typ.), 2,081 BTU/hr (max.) |
| Operating Temperature | 0 °C to 40 °C |
| Operating Humidity | 10% to 90% |
Certifications
| Safety | CB / NRTL |
| EMC | FCC Class A / CE / KC |
| ErP / Energy Star | Yes / Yes |
Compatibility & Software Support
Platform
Android 13 with 64 GB internal memory. Features listed by LG include Screen Share, PIP and PBP with external sources, booting logo image, auto brightness sensor and power indicator.
LG Software
| LG ConnectedCare | Yes |
| LG ConnectedCare DMS | Yes |
Control & Integration
RS-232C and RJ45 (LAN) control, Smart Energy Saving and Wake on LAN. OPS slot supported with built-in OPS power; the OPS PC itself is not included.
Package Contents & TR3DK Series Ordering Information
In the Box
Power cord (3 m), USB cable Type-A to Type-B (5 m), USB Type-C to Type-C cable (1.8 m), HDMI cable (3 m), writing pens (2), remote controller, Wi-Fi module, user manual and quick setup guide.
Optional Accessories (LG)
Wall mount WM-L000S and floor stand ST-000F. Wall brackets, stands and installation are not included in the price.
TR3DK Series Models
| Size | Part No. |
| 98" (this listing) | 98TR3DK-BM |
Datasheet & Downloads
| LG product page (Singapore, listed as 98TR3DK-B) | 98TR3DK-BM on lg.com/sg |
| LG spec sheet and datasheet (PDF) | 98TR3DK-BM on LG Commercial Display |
| Manuals | LG Business manual download |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting 98TR3DK-BM.
Frequently Asked Questions — LG 98TR3DK-BM
Does it need a separate PC?
No. The built-in Android 13 system with 8 GB RAM and 64 GB storage runs on its own. You can also connect a laptop over HDMI or USB Type-C, or fit an optional OPS slot-in PC.
How many touch points does it support?
LG specifies up to 40 touch points with Windows and up to 32 with Android.
Can it run 24/7 or be mounted in portrait?
LG rates the 98TR3DK-BM for 16 hours a day, 7 days a week, landscape only.
Is a wall bracket included?
No. At 103.6 kg the head needs a properly rated mount; brackets, stands and installation are quoted separately. LG's optional accessories are the WM-L000S wall mount and ST-000F floor stand, and the VESA pattern is 800 x 600 mm.
What warranty do I get?
3 years local on-site warranty in Singapore, supplied by SourceIT with a GST invoice.
