LG 49VL5PJ 49" FHD Video Wall Display, 500 nit, 24/7, webOS 4.1
PRODUCT DESCRIPTION
LG 49VL5PJ 49" FHD Slim Bezel Video Wall (49VL5PJ) - 3 Years Local Warranty
Slim-Bezel FHD Panel for Tiled Video Walls
The LG 49VL5PJ is the 49-inch panel in LG's VL5PJ video wall series. It pairs a 1,920 x 1,080 IPS panel with 500 nit brightness and a low 3% haze surface, and LG rates it for 24/7 operation with a 60,000-hour typical (50,000-hour minimum) lifetime.
Narrow Bezel Layout
LG lists bezel widths of 2.25 mm (top and left) and 1.25 mm (bottom and right), and Tile Mode supports arrays of up to 15 x 15 panels in portrait or landscape. Each panel has a DP output for passing HDMI, DVI or DP signals to the next display.
webOS 4.1 with Built-In Content Tools
webOS 4.1 with 8 GB internal memory provides local content scheduling, Group Manager, USB Plug & Play, Play via URL, gapless playback, Video Tag, RS-232C and local network sync, and fail over. Temperature, backlight and gyro sensors are built in.
Tested for Dust, Managed Remotely
LG lists the 49VL5PJ as IP5X tested. It works with LG SuperSign CMS, SuperSign Control / Control+, SuperSign WB, SuperSign Media Editor and LG ConnectedCare, and supports Crestron Connected, SNMP and Wake on LAN.
Planning a video wall? Email sales@sourceit.com.sg with the wall size, layout (for example 2 x 2 or 3 x 3) and content source, and we will help you spec the panels.
LG 49VL5PJ Datasheet — Technical Specifications
General
| Product Name | LG 49VL5PJ 49" FHD Slim Bezel Video Wall |
| Part Number | 49VL5PJ |
| Series | VL5PJ Video Wall |
| Local Warranty (Singapore) | 3 years on-site, supplied by SourceIT with a GST invoice |
Panel
| Screen Size | 49" |
| Panel Technology | IPS |
| Native Resolution | 1,920 x 1,080 (FHD), 16:9, 60 Hz |
| Brightness | 500 nit |
| Contrast Ratio | 1,000:1; dynamic 500,000:1 |
| Colour Gamut | NTSC 72% |
| Colour Depth | 10 bit, 1.07 billion colours |
| Viewing Angle (H x V) | 178 x 178 |
| Response Time | 8 ms (G to G) |
| Surface Treatment (Haze) | 3% |
| Lifetime | 60,000 hours (typ.), 50,000 hours (min.) |
| Operation Hours | 24/7 |
| Portrait / Landscape | Yes / Yes |
Connectivity
| Inputs | HDMI x 2 (HDCP 2.2), DisplayPort (HDCP 2.2), DVI-D (HDCP 1.4), Audio In, RS-232C In, RJ45 (LAN), IR In, USB 2.0 Type-A |
| Outputs | DP Out (input: HDMI / DVI / DP), Audio Out, RS-232C Out |
Mechanical
| Bezel | Black; T / R / L / B 2.25 / 1.25 / 2.25 / 1.25 mm |
| Dimensions (W x H x D) | 1,077.6 x 607.8 x 89.7 mm |
| Weight (Head) | 16.9 kg |
| Carton Dimensions (W x H x D) | 1,198 x 247 x 756 mm |
| Packed Weight | 21.9 kg |
| Handle | Yes |
| VESA Mount | 600 x 400 mm |
Power & Environment
| Power Supply | AC 100–240 V, 50/60 Hz, built-in power |
| Power Consumption | 110 W typ. / 120 W max.; Smart Energy Saving 70 W; DPM 0.5 W; power off 0.5 W |
| Heat Dissipation | 375 BTU/hr (typ.), 409 BTU/hr (max.) |
| Operating Temperature | 0 °C to 40 °C |
| Operating Humidity | 10% to 80% |
| IP Rating | IP5X tested |
Certifications
| Safety | CB / NRTL |
| EMC | FCC Class A / CE / KC |
| ErP | Yes (EU only) |
Compatibility & Software Support
Platform
LG webOS 4.1 with 8 GB internal memory. Features listed by LG include embedded CMS (local contents scheduling, Group Manager), USB Plug & Play, Fail Over, no-signal background image, RS-232C and local network sync, Video Tag (4), Play via URL, screen and external-input rotation, gapless playback, Tile Mode (max. 15 x 15), setting data cloning, ISM method, Auto Set ID, status mailing, SI server setting, webRTC, Pro:Idiom, white balance by grey scale and scan inversion.
LG Software
| SuperSign CMS | Yes |
| SuperSign Control / Control+ | Yes |
| SuperSign WB | Yes |
| SuperSign Media Editor | Yes |
| LG ConnectedCare | Yes |
Control & Integration
Crestron Connected, SNMP, Control Manager, Smart Energy Saving, PM Mode, Wake on LAN, Network Ready and HDMI-CEC.
Package Contents & VL5PJ Series Ordering Information
In the Box
Remote controller (with 2 batteries), power cord, RS-232C cable, LAN cable, DP cable, IR receiver and manual.
Mounting
LG does not list optional accessories for this model on its spec page. Video wall mounts, frames and installation are not included in the price.
VL5PJ Series Models
| Size | Part No. |
| 49" (this listing) | 49VL5PJ |
| 55" | 55VL5PJ |
Datasheet & Downloads
| LG product page (Singapore, listed as 49VL5PJ-A) | 49VL5PJ on lg.com/sg |
| LG spec sheet and datasheet (PDF) | 49VL5PJ on LG Commercial Display |
| Manuals | LG Business manual download |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting 49VL5PJ.
Frequently Asked Questions — LG 49VL5PJ
How large a wall can I build?
LG's Tile Mode supports arrays of up to 15 x 15 panels.
What is the bezel width?
LG lists 2.25 mm on the top and left and 1.25 mm on the bottom and right of each panel.
Is it suitable for 24/7 use?
Yes. LG rates it for 24/7 operation with a 60,000-hour typical lifetime.
Is a wall bracket included?
No. Video wall mounts and installation are quoted separately; the VESA pattern is 600 x 400 mm.
What warranty do I get?
3 years local on-site warranty in Singapore, supplied by SourceIT with a GST invoice.
