Ergotron 200 Series Combo Arm White
PRODUCT DESCRIPTION
Ergotron 200 Series Combo Arm White (45-230-216) - 5 Years Local Warranty
Looking for a genuine Ergotron 200 Series Combo Arm White in Singapore? The 200 Series Combo Arm White (45-230-216) is an official Ergotron 200 Series monitor arm in white finish. It takes displays up to 24" (61 cm), holds 6–18 lbs (2.7–8.2 kg), offers 5" (12.7 cm) of height adjustment and uses VESA MIS-D mounting. SourceIT supplies it with the 5-year Ergotron warranty, local support and a GST invoice for businesses, schools, hospitals and government agencies in Singapore.
200 Series Combo Arm — Keyboard & Monitor Mount
Attach your monitor and keyboard to the 200 Combo and free up space. Features 3-point telescoping motion, providing greater reach to bring the system to where it’s needed. This combination wall mount accommodates monitor, bar-code scanner, keyboard, wrist rest and mouse. A unique cable management system conceals and organizes cords, making cleaning a snap!
Key Features of the 200 Series Combo Arm White
Easily position flat panel monitor and keyboard for maximum comfort and productivity
Distance between screen and keyboard is adjustable
Five-inch (13 cm) LCD height adjustment
Rugged steel construction
Extremely easy to clean; promotes infection control
Barcode scanner holder provides easy access to hand-held scanner
Extends keyboard out up to 39" (99 cm); fold equipment back out of the way when not in use. With the keyboard folded up, total system depth is as little as 12.1" (31 cm)
Ergonomic negative-tilt keyboard tray with left or right mouse tray ensures wrists remain in a neutral position during data entry
Constant Force, patented lift technology provides fluid, one-touch adjustment of LCD
Clean, concealed and neat routing of cables through the expansive cable management system
Popular Uses for the 200 Series Combo Arm White
- Home office and hybrid-work desks that need more usable desk space
- Hot-desking and open-plan offices where every user adjusts the screen to their own height
- Sit-stand desks — the arm clamps to the worksurface and moves with it
- Trading, design and control-room desks where screens are repositioned through the day
Buy the 200 Series Combo Arm White in Singapore from SourceIT
Ergotron backs the 200 Series Combo Arm White with a 5-year manufacturer warranty. SourceIT supplies it with local Singapore warranty support and a GST invoice, and can quote volume pricing for corporate, education, government and healthcare projects.
Ergotron 200 Series Combo Arm White Datasheet — Technical Specifications
General
| Product Name | 200 Series Combo Arm (white) |
| Part Number | 45-230-216 |
| Finish / Colour | White |
| Product Type | Keyboard & Monitor Mount |
| Series | 200 |
| Product Category | Wall Workstation |
| Mount Type | Wall Workstation |
| Device Type | Monitor & keyboard |
| Technology | none |
| GTIN / UPC | 698833010572 |
Specifications
| Height Adjustment | 5" (12.7 cm) |
| Display Size | Up to 24" (61 cm) |
| VESA Compliance | VESA MIS-D |
| Tilt | 30° |
| Pan | 360° |
| Screen Rotation | 360° |
| Weight Capacity | 6–18 lbs (2.7–8.2 kg) |
Dimensions & Weight
| Product Weight | 18.1 lbs (8.2 kg) |
| Shipping Weight | 25.9 lbs (11.7 kg) |
| Shipping Dimensions (W x H x D) | 12.4 x 23.6 x 20" (31.5 x 59.9 x 50.8 cm) |
Certifications & Compliance
| HCAI / OSHPD | HCAI / OSHPD Preapproved with Wall Track installation |
| VESA Compliant | VESA Mount Standard Compliant |
Warranty
| Manufacturer Warranty | 5-Year Manufacturer Warranty (Ergotron) |
| Local Warranty (Singapore) | Supplied by SourceIT with local warranty support and GST invoice |
Compatibility & Fit
Attach your monitor and keyboard to the 200 Combo and free up space. This wall mount solution features 3-point telescoping motion, providing greater reach to bring the system to where it’s needed.
- Display size: Up to 24" (61 cm)
- Weight capacity: 6–18 lbs (2.7–8.2 kg)
- VESA: VESA MIS-D mounting interface
- Designed for: Monitor & keyboard
Not sure it fits? Send our team the model numbers of your display, desk, wall or cart and we will confirm compatibility before you order.
Package Contents & Ordering Information
In the box: the Ergotron 200 Series Combo Arm White (45-230-216) with the mounting hardware Ergotron supplies for it. The installation manual under Datasheet & Downloads lists every part included.
Other Options in This Ergotron Family
| Part Number | Description |
| 45-230-216 (this listing) | 200 Series Combo Arm (white) |
| 45-230-200 | 200 Series Combo Arm (black) |
Need a different configuration or finish? Tell our team what you need and we will quote the correct Ergotron part number.
Datasheet & Downloads
- Ergotron 200 Series Combo Arm — official product page (ergotron.com)
- Dimensional Drawing: dim-200combo (PDF, media.ergotron.com)
- Product Sheet: 200 Series Combo Arm (PDF, media.ergotron.com)
- Installation Manual: 888-45-163-w (PDF, media.ergotron.com)
Specifications on this page are taken from Ergotron's official product data. For a written quotation, stock position or delivery lead time in Singapore, contact SourceIT.
Frequently Asked Questions — Ergotron 200 Series Combo Arm White
What warranty does the Ergotron 200 Series Combo Arm White come with in Singapore?
Ergotron provides a 5-year manufacturer warranty. Every unit sold by SourceIT comes with local Singapore warranty support and a GST invoice.
How much weight does it support?
Ergotron rates it at 6–18 lbs (2.7–8.2 kg). Check your device's published weight before ordering.
What display size does it take?
Ergotron lists a display size of up to 24" (61 cm). Heavier panels are limited by the weight capacity rather than the diagonal.
Is it VESA compatible?
Yes. It uses the VESA MIS-D mounting interface found on most business monitors.
Where can I find the installation instructions?
Ergotron's installation manual is linked under Datasheet & Downloads on this page.
Can SourceIT supply this for a corporate, education or healthcare project?
Yes. Contact SourceIT for a written quotation, volume pricing and delivery lead time in Singapore.
