D-Link DWM-311-G 5G NR Industrial M2M VPN Modem
PRODUCT DESCRIPTION
D-Link DWM-311-G 5G NR Industrial M2M VPN Modem (DWM-311-G) - 3 Years Local Warranty
5G Speed for Connected Machines
The D-Link DWM-311-G is a compact 5G M2M modem built on a 3GPP Rel. 16 5G/4G module. It supports 5G SA and NSA on Sub-6 GHz, with D-Link-rated throughput of up to 3.4 Gbps downlink (5G NSA) and LTE fallback (DL Cat.19 / UL Cat.18).
2.5 GbE Wired Connection
A single 2.5 Gigabit RJ45 LAN port carries that bandwidth to your equipment — ideal for EV chargers, digital signage, kiosks and remote cameras that need a fast, plug-and-play cellular uplink.
Industrial-Grade Design
A robust metal build, -30 to 70 °C operating range, wide DC 5-32 V terminal-block input and wall or DIN-rail mounting suit roadside cabinets and plant rooms.
VPN, SMS and Cloud Management
An OpenVPN client secures traffic, SMS event management sends alerts, and units can be configured via Web UI or SSH and managed centrally with D-Link D-ECS2.
Need help choosing? Email sales@sourceit.com.sg with your site, carrier and bandwidth needs and we will recommend the right M2M modem.
D-Link DWM-311-G Datasheet — Technical Specifications
General
| Product Name | D-Link DWM-311-G 5G M2M Modem |
| Part Number | DWM-311-G |
| Series | D-Link 5G/4G LTE Industrial M2M Modems |
| Local Warranty (Singapore) | 3 years, supplied by SourceIT with a GST invoice |
Cellular
| Cellular Module | 5G/4G 3GPP Rel. 16 |
| Cellular Standards | 5G NR (Sub-6GHz), 4G LTE (DL Cat.19 / UL Cat.18) |
| 5G NSA Throughput | 3.4 Gbps (DL) / 550 Mbps (UL) |
| 5G SA Throughput | 2.4 Gbps (DL) / 900 Mbps (UL) |
| LTE Throughput | 1.6 Gbps (DL) / 200 Mbps (UL) |
| 5G NR Bands (EU SKU) | n1/n3/n5/n7/n8/n20/n28/n38/n40/n41/n71/n75/n76/n77/n78 |
| 4G LTE Bands (EU SKU) | FDD B1/B3/B5/B7/B8/B20/B28/B32/B71; TDD B38/B40/B41/B42/B43 |
Interfaces
| Ethernet | 1 x RJ45 LAN 2.5GE |
| SIM Slot | 1 x SIM (3FF Micro) |
| Antenna Connectors | 4 x SMA(F) cellular |
| Power Input | DC 5-32V (terminal block, 2-pin) |
Network, VPN & Administration
| Network Features | NAT, Bridge Mode, ICMP checking, DHCP Server, Virtual Server, DDNS (DynDNS, No-IP, Dynamic DO), IPv4/v6 |
| VPN | OpenVPN (client mode) |
| Configuration | Web UI, SSH |
| Management | D-Link D-ECS2 |
| System & Scheduling | FW upgrade, reboot & reset, system time, NTP; reboot rule policy, working day |
| SMS Service | SMS Inbox, SMS Event Management |
Physical & Environmental
| Dimensions | 77.4 x 68.5 x 26 mm |
| Operating Temperature | -30 to 70 °C |
| Storage Temperature | -40 to 85 °C |
| Humidity | Operating 10% to 95%; storage 0 to 95% (non-condensing) |
| Certifications | CE, UKCA, FCC, PTCRB |
Compatibility & Software Support
Management
Web UI and SSH for local configuration; D-Link D-ECS2 for central cloud management; SMS inbox and event alerts.
Typical Use
High-bandwidth 5G uplink for a single Ethernet device such as an EV charger, digital signage player, kiosk or IP camera, or as a failover link.
Package Contents & M2M Modem Ordering Information
Package Contents
4 x cellular SMA antennas, 1 x RJ-45 cable, 1 x power adapter, 1 x terminal block (2-pin).
D-Link M2M Modem Models
| Model | Cellular | LAN / SIM | Part No. |
| DWM-311 | 4G LTE | 1 x GE / 1 SIM | DWM-311 |
| DWM-311-G (this listing) | 5G NR / 4G LTE | 1 x 2.5GE / 1 SIM | DWM-311-G |
| DWM-314-T | 4G LTE Cat.4 | 4 x FE / 1 SIM | DWM-314-T |
| DWM-314-G | 5G NR / 4G LTE | 4 x GE / 2 SIM | DWM-314-G |
Datasheet & Downloads
| D-Link datasheet | DWM-311-G Datasheet (PDF) |
| D-Link product page | DWM-311-G on dlink.com |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting DWM-311-G.
Frequently Asked Questions — D-Link DWM-311-G
Does it support 5G standalone (SA)?
Yes. D-Link lists both 5G SA and NSA, with up to 2.4 Gbps DL on SA and 3.4 Gbps DL on NSA.
How many SIM cards does it take?
One Micro-SIM (3FF). For dual-SIM failover see the DWM-314-G.
What power input does it need?
DC 5-32 V via a 2-pin terminal block; a power adapter is included.
Does it support VPN?
Yes, OpenVPN in client mode.
What warranty do I get?
3 years local warranty in Singapore, supplied by SourceIT with a GST invoice.
