D-Link DMS-3130-30TS 30-Port L3 Stackable Multi-Gigabit Switch
PRODUCT DESCRIPTION
D-Link DMS-3130-30TS 30-Port Layer 3 Stackable Multi-Gigabit Managed Switch with 25G SFP28 Uplinks (DMS-3130-30TS) - 5 Years Local Warranty
2.5G Access with 10G and 25G Uplinks
The D-Link DMS-3130-30TS provides 24 x 100M/1G/2.5GBASE-T ports, 2 x 100M/1G/2.5G/5G/10GBASE-T ports and 4 x 10G/25G SFP28 ports.
Physical Stacking up to 9 Units
Stack up to 9 units with 200 Gbps of stacking bandwidth. D-Link rates the switch at 360 Gbps switching capacity and 268 Mpps forwarding.
Full Layer 3 Managed
Static routing, RIP, OSPFv2/v3 and VRRP, ERPS, Q-in-Q, 802.1X and IP-MAC-Port Binding, managed via web GUI or CLI with a dedicated out-of-band management port. D-Link lists support for AC/DC redundant power.
Need help choosing? Email sales@sourceit.com.sg with your port count, uplink and stacking needs and we will size it for you.
D-Link DMS-3130-30TS Datasheet — Technical Specifications
General
| Product Name | D-Link DMS-3130-30TS Layer 3 Stackable Multi-Gigabit Managed Switch |
| Part Number | DMS-3130-30TS |
| Series | DMS-3130 Layer 3 Stackable Multi-Gigabit Managed Switches |
| Local Warranty (Singapore) | 5 years, supplied by SourceIT with a GST invoice |
Interfaces
| 2.5G Ports | 24 x 100M/1G/2.5GBASE-T |
| 10G Copper | 2 x 100M/1G/2.5G/5G/10GBASE-T |
| 25G Fibre | 4 x 10G/25G SFP28 |
| Management | RJ-45 console port, RJ-45 out-of-band management port, 1 x USB 2.0 Type A |
| PoE | Not supported (see DMS-3130-30PS) |
Performance & Stacking
| Switching Capacity | 360 Gbps |
| Maximum Forwarding Rate | 268 Mpps |
| MAC Address Table | 32K entries |
| Packet Buffer | 4 MB |
| Jumbo Frames | Up to 9 KB |
| Physical Stacking | Up to 9 units, 200 Gbps stacking bandwidth |
Physical & Environmental
| Dimensions | 440 x 250 x 44 mm |
| Weight | 3.63 kg |
| Power Input | 100–240 VAC, 50–60 Hz |
| Power Consumption | Standby 43.84 W; max 74.26 W |
| Cooling | 2 x smart fans |
| Acoustic | Max 52.5 dB / Min 41.0 dB |
| Operating Temperature | 0 to 50 °C |
| Storage Temperature | -40 to 70 °C |
| Operating Humidity | 10% to 90% RH |
| MTBF | 270,341 hours |
Certifications
| EMI | FCC Class A, CE Class A, VCCI Class A, IC, RCM, BSMI |
| Safety | CB, cUL, BSMI |
Compatibility & Software Support
Layer 3
Static routing (512 IPv4 / 256 IPv6 routes), RIPv1/v2/RIPng, OSPFv2/v3 and VRRP v2/v3, with 1,024 hardware routing entries.
Layer 2 & QoS
Up to 4K VLANs, link aggregation (32 groups per device, 8 ports per group), ERPS ring protection, Q-in-Q and 8 QoS queues per port.
Security
802.1X, IP-MAC-Port Binding, DHCP snooping and ACLs (3,072 ingress / 1,024 egress hardware entries).
Management
Web GUI, CLI via console, dedicated out-of-band management port, USB 2.0 port, SNMP v1/v2c/v3, syslog and RMON v1/v2.
Optional Modules (per D-Link)
SFP+: DEM-431XT, DEM-432XT. SFP28: DEM-S2801SR, DEM-S2810LR. DAC: DEM-CB100S, DEM-CB300S, DEM-CB100S28, DEM-CB100Q28-4S28.
Package Contents & DMS-3130 Ordering Information
DMS-3130 Models
| Model | Ports | PoE Budget | Part No. |
| DMS-3130-30TS (this listing) | 24 x 2.5G + 2 x 10GBASE-T + 4 x 25G SFP28 | — | DMS-3130-30TS |
| DMS-3130-30PS | 16 x 2.5G PoE+ + 8 x 5G PoE++ + 2 x 10GBASE-T + 4 x 25G SFP28 | 740 W (960 W with 2 PSUs) | DMS-3130-30PS |
Package contents are not listed in D-Link's datasheet — ask us if you need confirmation of the included power cord, console cable and rack-mount kit.
Datasheet & Downloads
| D-Link datasheet | DMS-3130 Series Datasheet (PDF) |
| D-Link product page | DMS-3130-30TS on dlink.com |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting DMS-3130-30TS.
Frequently Asked Questions — D-Link DMS-3130-30TS
Is it a PoE switch?
No. For PoE, see the DMS-3130-30PS (740 W, up to 960 W with a second PSU).
What speeds do the ports support?
24 ports run at 100M/1G/2.5G, 2 ports at up to 10G over copper, and 4 SFP28 ports at 10G or 25G.
Can I stack it?
Yes, up to 9 units with 200 Gbps stacking bandwidth.
Does it support dynamic routing?
Yes. D-Link lists RIP, OSPFv2/v3 and VRRP.
What warranty do I get?
5 years local warranty in Singapore, supplied by SourceIT with a GST invoice.
