AMD Ryzen Threadripper 9960X 24-Core 48-Thread sTR5 Workstation Processor
PRODUCT DESCRIPTION
AMD Ryzen Threadripper 9960X 24-Core 48-Thread sTR5 Workstation Processor (100-100001595WOF) - 3 Years Local Warranty
24 Cores for High-End Desktops
The AMD Ryzen Threadripper 9960X brings 24 Zen 5 cores and 48 threads to the sTR5 platform, with 128 MB of L3 cache and clocks from 4.2 GHz up to 5.4 GHz. It is built for rendering, simulation, compilation, AI development and other heavily threaded work that outgrows mainstream desktops.
sTR5 Platform
It installs in sTR5 motherboards (TRX50) and supports 4-channel DDR5 RDIMM memory, with PCIe 5.0 connectivity (88 usable lanes from the CPU). Base clock is 4.2 GHz, boost reaches up to 5.4 GHz, and default TDP is 350 W.
Discrete Graphics Required
This processor has no integrated graphics, so a discrete graphics card is required for display output.
Building workstations or buying for a team? Email sales@sourceit.com.sg for volume pricing and delivery lead time.
AMD Ryzen Threadripper 9960X Datasheet — Technical Specifications
General
| Product Name | AMD Ryzen Threadripper 9960X |
| Boxed Part Number (OPN) | 100-100001595WOF |
| Tray Part Number | 100-000001595 |
| Series | Ryzen Threadripper 9000 Series (former codename Shimada Peak) |
| Market Segment | Enthusiast Desktop |
| Local Warranty (Singapore) | 3 years, AMD boxed processor limited warranty, supplied by SourceIT with a GST invoice |
CPU
| Architecture | Zen 5 |
| Cores / Threads | 24 / 48 (SMT) |
| Base Clock | 4.2 GHz |
| Max. Boost Clock | Up to 5.4 GHz |
| L1 Cache | 1920 KB |
| L2 Cache | 24 MB |
| L3 Cache | 128 MB |
| Default TDP | 350 W |
| Process | TSMC 4nm FinFET (CPU cores); TSMC 6nm FinFET (I/O die) |
| Max. Operating Temperature (Tjmax) | 95 °C |
| Boost Technology | Precision Boost 2 |
| Overclocking & Tuning | Unlocked for overclocking, Precision Boost Overdrive, Curve Optimizer voltage offsets |
| Instruction Set Extensions | AES, AMD-V, AVX, AVX2, AVX-512, FMA3, MMX-plus, SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64 |
Platform & Memory
| CPU Socket | sTR5 |
| Supporting Chipsets | TRX50 |
| Memory Type | DDR5 RDIMM, 4 channels |
| Max. Memory Speed | Up to 6400 MT/s |
| ECC Support | Yes (Default Enabled) |
| Memory Overclocking | AMD EXPO Technology |
Connectivity
| PCI Express Version | PCIe 5.0 |
| Native PCIe Lanes | 92 total / 88 usable |
| NVMe Support | Boot, RAID 0, RAID 1, RAID 5, RAID 10 |
| Native USB | 4 x USB 3.2 Gen 2 (10Gbps) |
| Native SATA Ports | 2 |
Graphics
| Integrated Graphics | None, discrete graphics card required |
Security & Manageability
| DASH Manageability | Yes |
| AMD Memory Guard | Yes |
| AMD Secure Processor | Yes |
| Firmware TPM | Yes |
| Windows Secured-core PC | Yes |
| Virtualisation | AMD-V, AMD-Vi (IOMMU), SLAT, AVIC |
Cooling
| Thermal Solution in Box | Not included |
Compatibility & Software Support
Motherboard
Requires an sTR5 motherboard (TRX50). Boards may need a BIOS update before they recognise a newer processor, so check the motherboard maker's CPU support list before installing.
Memory
DDR5 RDIMM memory only (registered ECC DIMMs), 4 channels. AMD EXPO memory profiles are supported.
Operating Systems
Windows 11 64-bit, RHEL x86 64-bit, Ubuntu x86 64-bit, Windows 10 64-bit.
Software
AMD Ryzen Master for monitoring and tuning, and the AMD Chipset Driver from AMD Drivers & Support.
Typical Use
Workstations for 3D rendering, VFX, simulation, CAD/CAE, software builds, data science and AI development.
Package Contents & AMD Ryzen Threadripper 9000 & PRO 9000 WX-Series Ordering Information
In the Box
AMD Ryzen Threadripper 9960X processor in retail packaging. No CPU cooler is included, so budget for a compatible cooler.
AMD Ryzen Threadripper 9000 & PRO 9000 WX-Series
| Model | Key feature |
| Ryzen Threadripper PRO 9995WX | 96C/192T, up to 5.4 GHz, 350W |
| Ryzen Threadripper PRO 9985WX | 64C/128T, up to 5.4 GHz, 350W |
| Ryzen Threadripper PRO 9975WX | 32C/64T, up to 5.4 GHz, 350W |
| Ryzen Threadripper PRO 9965WX | 24C/48T, up to 5.4 GHz, 350W |
| Ryzen Threadripper PRO 9955WX | 16C/32T, up to 5.4 GHz, 350W |
| Ryzen Threadripper 9980X | 64C/128T, up to 5.4 GHz, 350W |
| Ryzen Threadripper 9970X | 32C/64T, up to 5.4 GHz, 350W |
| Ryzen Threadripper 9960X (this listing) | 24C/48T, up to 5.4 GHz, 350W |
Datasheet & Downloads
| AMD product page | AMD Ryzen Threadripper 9960X specifications on amd.com |
| Drivers & software | AMD Ryzen Threadripper 9960X drivers and downloads |
| Tuning utility | AMD Ryzen Master |
Need a PDF sent directly? Email sales@sourceit.com.sg quoting 9960X.
Frequently Asked Questions — AMD Ryzen Threadripper 9960X
Does the 9960X come with a cooler?
No. The boxed 9960X ships without a cooler.
Which motherboards does it fit?
sTR5 motherboards (TRX50). It does not fit AM5 or older Threadripper sockets.
Does it have integrated graphics?
No. A discrete graphics card is required for display output.
What memory does it support?
4-channel DDR5 RDIMM, up to 6400 MT/s.
What warranty do I get?
3 years AMD boxed processor limited warranty, supplied locally by SourceIT with a GST invoice.
